E1230™ 1200mm x 300mm 36W LED Flat Panel



The E1230™ has been upgraded to produce 95lm/W for outstanding energy savings. The light guide board and diffuser have been engineered to ensure maximum light output and complete uniformity. Suitable for a wide range of applications including office, education and commercial spaces.

SKU Code Description
EN-CRM1230A 1200 x 300mm Panel Recess Mount
EN-LPEM2 3 Hour Emergency Pack for Panel Range
EN-SK100B Panel Adjustable Suspension Kit
EN-SM107B 1200 x 300 x 74mm Panel Surface Mount
Please Note: May not be compatible with PIR’s. Please contact sales office for compatibility
Downloads
All IES/LDT Files
Features & Benefits
Edge-lit design and optical pattern light guide engineered for even light distribution
Suitable for installation in 15 & 24mm T-bar ceilings
SDCM <5 providing consistent light colour quality
UGR 19 (Unified Glare Rating) - suitable for use in offices
Flicker free driver - Power Factor >0.9
Life not affected by frequent switching e.g. when used with occupancy controls
1-10V dimmable, DALI and emergency versions available
Surface mount box and adjustable suspension kit available
1.5kV surge protection
3 year warranty
Read More
Technical Information
Lifetime (Hours)
30000
Power Factor
0.9
IP Rating
IP20
Length (mm)
1195
Width (mm)
295
Height (mm)
10
DALI
No
  • CE
    CE
  • SEAI
    SEAI
  • Class 2 Equipment
    Class 2 Equipment
  • Equipment for Indoor Use
    Equipment for Indoor Use
  • IP20
    IP20
