7-10W Non-Dimmable Constant Current Driver

7-10W 350mA Non-Dimmable Constant Current LED Driver. For Constant Current LED lamps or luminaires it is necessary to wire the circuit in series in order for the current to remain constant. Overload, thermal & short-circuit protection. 1.0kV SURGE PROTECTION – EN 61547. Safety compliance - EN 61347, UL8750, UL1310, UL1012. EMC compliance - EN 55015, EN 61000, EN 61547. 3 year warranty.

Spec Sheet


  • Registered Community Design 001886730
  • For Constant Current LED lamps or luminaires it is necessary to wire the circuit in series in order for the current to remain constant
  • Overload, thermal & short-circuit protection
  • 1.0kV SURGE PROTECTION – EN 61547
  • Safety compliance - EN 61347, UL8750, UL1310, UL1012
  • EMC compliance - EN 55015, EN 61000, EN 61547
  • 3 Year guarantee

Input Voltage (Min)
100
Input Voltage (Max)
240
Input Voltage Type
AC
IP Rating
IP20
Height (mm)
27
Length (mm)
145

Download

Instruction Leaflet
