QuaZar™ 20W Adjustable IP65 Driverless LED Floodlight

The IP65 driverless range of QuaZar™ floodlights incorporate the latest in high voltage LED technology. With their ultra slim profile and high performance, now you can light your external areas and gardens without sacrificing the appearance. Available in 10W, 20W, 30W and 50W versions.

Spec Sheet


  • IP65 rated LED floodlight with ultra slim design for minimal visual impact
  • IK08 rated aluminium housing and tempered glass provides excellent protection
  • Available in matt black and matt white finish housing
  • Pre-wired with 800mm of cable
  • 1.5kV surge protection
  • 3 year warranty
SKU Code Wattage Lumens Colour Temp (K) Ra Beam Angle Download
EN-FLH20BLK/40 20 1800 4000 70 120
EN-FLH20W/40 20 1800 4000 70 120

Bracket Length (mm)
100
Positional Adjustment
Adjustable
Width (mm)
167
Height (mm)
127
Bracket Width (mm)
174
Depth (mm)
26
IP Rating
IP65
Dimmable
No
DALI
No
Input Voltage Type
AC
Input Voltage (Min)
180
Input Voltage (Max)
265
Power Factor
0.9
Lifetime (Hours)
25000
Switching Cycles
15000

Download

Instruction Leaflet
Please Note: May not be compatible with PIR’s. Please contact sales office for compatibility
