EFD™ GU10 Adjustable Baffled Fire Rated Downlight

Completing the EFD™ range this adjustable, fire rated, baffled GU10 downlight has been designed to reduce direct glare from the light source. Available in matt white and white finish with black baffle.

Spec Sheet


  • Black baffle fire rated downlight with recessed lamp reduces direct glare
  • Adjustable up to 20°
  • Lock ring for ease of lamp replacement
  • Fibre based insulation coverable when used with insulation cap (included)
  • Tested in 30, 60 and 90-minute fire rated ceilings
  • 3 year warranty
SKU Code Max. Lamp Wattage Download
EN-DLM482MWB 50
EN-DLM482WB 50

Positional Adjustment
Adjustable
Height (mm)
135
Recess Depth (mm)
115
Overall Diameter (mm)
95
Cutout Diameter Min. (mm)
80
IP Rating
IP20
Dimmable
Yes
Input Voltage Type
AC
Input Voltage (Min)
240
Input Voltage (Max)
240

Download

Instruction Leaflet
