2 x 50W IP67 Non-Dimmable 12V Constant Voltage Driver

12V DC Non-Dimmable IP67 Constant Voltage LED Driver.

Spec Sheet


  • For the supply of low voltage LED lamps
  • 2 x 50W outputs
  • Short circuit protection
  • Thermal protection
  • Pre-wired with 150cm primary lead
  • Pre-wired with 120cm secondary leads
  • 1.2m Output cable
  • 1.0kV SURGE PROTECTION – EN 61547
  • Safety compliance – EN 61347
  • EMC compliance – EN 55015, EN 61000, EN 61547
  • Non-dimmable
  • Parallel wiring only
  • 12V DC output, 50/60Hz
  • 3 Year Warranty - see www.auroralighting.com for details
SKU Code Wattage
AU-LED10012CV 100

Positional Adjustment
Fixed
Length (mm)
240
Width (mm)
67
Height (mm)
50
IP Rating
IP67
Dimmable
No
Input Voltage Type
AC
Input Voltage (Min)
110
Input Voltage (Max)
250

Download

Instruction Leaflet
