3-6W Non-Dimmable Constant Current Driver

Spec Sheet


  • Constant current LED driver for use with 350mA 1W LEDs
  • 350mA Constant current output
  • Suitable for the supply of 3-6 1W LEDs
  • Overload protection
  • Short-circuit protection
  • Thermal protection
  • Loop-in, loop-out primary wiring terminals
  • Integrated earth terminal for earth continuity
  • No junction box required
  • 1.0kV SURGE PROTECTION – EN 61547
  • Safety compliance - EN 61347
  • EMC compliance - EN 55015, EN 61000, EN 61547
  • Non-dimmable
  • Series wiring only
  • 3 Year Warranty - see www.auroralighting.com for details

Length (mm)
95
Width (mm)
38
Height (mm)
24
IP Rating
IP20
Input Voltage Type
AC
Input Voltage (Min)
100
Input Voltage (Max)
264
