Driver LED corriente constante no regulable 20W 1000mA

20W 1000mA Non-Dimmable Constant Current LED Driver. Constant current LED driver for use with 1000mA LEDs. Suitable for the supply of 1-20W LEDs. Overload protection/Short-circuit protection/Thermal protection. 1.0kV SURGE PROTECTION – EN 61547. Safety compliance - EN 61347. EMC compliance - EN 55015, EN 61000, EN 61547. Non-dimmable. 3 year warranty.

Hoja de especificaciones


  • Registered Community Design 001886730
  • Constant current LED driver for use with 1000mA LEDs
  • 1000mA Constant current output
  • Suitable for the supply of 1-20W LEDs
  • Overload protection
  • Short-circuit protection
  • Thermal protection
  • Loop-in, loop-out primary wiring terminals
  • Integrated earth terminal for earth continuity
  • No junction box required
  • 1.0kV SURGE PROTECTION – EN 61547
  • Safety compliance - EN 61347
  • EMC compliance - EN 55015, EN 61000, EN 61547
  • Non-dimmable
  • Series wiring only
  • 3 Year Warranty - see www.auroralighting.com for details

Width (mm)
40
Voltaje De Entrada (mín.)
100
Voltaje De Entrada (máx.)
240
Tipo De Voltaje De Entrada
AC
Clasificación De La Ip
IP20
Altura (mm)
31
Length (mm)
185
