20W Ballast

Technisches Datenblatt


  • Digitally controlled HID ballasts with built in starter
  • Flicker free light
  • Controlled lamp voltage regardless of supply voltage
  • Colour stability regardless of supply voltage
  • Lamp life increased by up to 50%
  • Lamp re-strike time reduced by up to 50%
  • Automatic disconnection of faulty lamps (End of Life Protection)
  • Short-circuit proof
  • Over temperature protection
  • Pulse packages produce starting energy
  • Polycarbonate case allows for use in Class I applications
  • SMD Technology
  • Silent operation
  • Built-in cable strain relief
  • Lightweight and compact
  • Safety compliance – EN 61347-1, EN 61347-2-1, EN 61347-2-3
  • EMC compliance – EN 55015, EN 61547, EN 61000-3-2
  • 5 Year guarantee (Subject to use of Philips or Osram Lamps)

Width (mm)
63
Eingangsspannung (Min)
220
Eingangsspannung (Max)
250
Eingangsspannung
AC
Höhe (mm)
31
Länge (mm)
115
