50W Dimmable Constant Current Driver

Spec Sheet


  • Registered Community Design 001886730
  • For Constant Current LED lamps or luminaires it is necessary to wire the circuit in series in order for the current to remain constant
  • AU-LEDD18035/AU-LEDD20035 can be dimmed with leading or trailing edge dimmers
  • Overload, thermal & short-circuit protection
  • Loop-in, loop-out primary wiring terminals
  • Integrated earth terminal for earth continuity
  • No junction box required
  • 1.0kV SURGE PROTECTION – EN 61547
  • Safety compliance - EN 61347, UL8750, UL1310, UL1012
  • EMC compliance - EN 55015, EN 61000, EN 61547
  • 3 Year Warranty - see www.auroralighting.com for details

Width (mm)
44
Input Voltage (Min)
220
Input Voltage (Max)
250
Input Voltage Type
AC
Height (mm)
33
Length (mm)
195
