30W Non-Dimmable Constant Current Driver

Spec Sheet


  • Registered Community Design 001886730
  • Constant current LED driver for use with 700mA LEDs
  • Overload protection
  • Short-circuit protection
  • Thermal protection
  • Loop-in, loop-out primary wiring terminals
  • Integrated earth terminal for earth continuity
  • No junction box required
  • 1.0kV SURGE PROTECTION – EN 61547
  • Safety compliance - EN 61347
  • EMC compliance - EN 55015, EN 61000, EN 61547
  • Non-dimmable
  • Series wiring only
  • 3 Year Warranty - see www.auroralighting.com for details

Width (mm)
40
Input Voltage (Min)
100
Input Voltage (Max)
240
Input Voltage Type
AC
Height (mm)
31
Length (mm)
185

Download

Instruction Leaflet
